The Schwank Style Series redefines what a commercial ceiling fan can be. Purpose-built for spaces where design and performance carry equal weight, this HVLS (High Volume, Low Speed) fan delivers powerful, whisper-quiet air circulation without compromising on aesthetics. Whether you're outfitting a restaurant patio, a boutique retail floor, or an upscale showroom, the Style Series fits in — and stands out.
Available in four sizes and six designer colours, every unit comes complete with advanced onboard smart voltage controls and integrated dimmable LED lighting. No add-ons. No extras. Just one sleek, all-in-one solution ready to perform from day one.
Why the Style Series?
At the heart of the Style Series is a Transverse Flux Brushless DC motor — one of the most efficient drive systems available in HVLS fans today. It moves between 27,000 and 45,000 CFM of air depending on the size selected, all while operating at an exceptionally quiet 39 dBA. That's the kind of background hum that disappears into your space rather than defining it.
The five injection-moulded, fiber-filled polypropylene blades are engineered for long-term durability and consistent airflow, mounted to an AISI 383 aluminum alloy hub with zinc-coated steel blade mount plates. The result is a fan built to last — backed by a lifetime warranty on blades, hub, and mounting system, and a 3-year warranty on the motor, gearbox, and control panel.
Specifications
| Specification | Details |
|---|---|
| Diameter options | 7 ft, 8 ft, 9 ft, 10 ft (2.1 m – 3.0 m) |
| Airflow | 27,000 – 45,000 CFM (size dependent) |
| Motor | Transverse Flux Brushless DC |
| Noise level | 39 dBA |
| Speed range | 0 – 120 RPM (variable) |
| Integrated lighting | 1,980 lumens dimmable LED (included) |
| Controls | Advanced onboard smart voltage controls (included) |
| Blades | 5 × injection-moulded fiber-filled polypropylene |
| Hub material | AISI 383 aluminum alloy with zinc-coated steel blade mount plates |
| Location rating | Indoor / Outdoor |
| Mounting | Universal mounting system and hardware included |
| Colour options | Black (Onyx), Blue (Cobalt), Grey (Slate), Red (Radiance), Silver (Sterling), White (Alabaster) |
| Certifications | UL and CSA certified |
| Warranty | Lifetime (blades, hub, mounting) · 3 years (motor, gearbox, controls) |
Ideal applications
The Style Series is a natural fit for any commercial environment where air movement and interior design need to coexist: restaurants and bar patios, retail showrooms, car dealerships, hotel lobbies, fitness centres, breweries, office spaces, and covered outdoor venues. If your space has a visual identity worth protecting, this is the fan that won't undermine it.
